HTPC-1264-TI4

$229.99 USD

Promoção Esgotado

Integrated Processor Intel N100

Bundles NO RAM NO SSD 4GB DDR4 128GB SSD 8GB DDR4 128GB SSD

Product Overview

The HTPC-1264-TI4 is a compact industrial mini PC built on the Intel® Processor N-series (FCBGA1264) platform, designed for reliable 24/7 operation in space-constrained deployments. With flexible I/O options, multiple display outputs (VGA + HDMI), and expandable connectivity via mPCIe and M.2 Key-B (3052), it is ideal for industrial control, edge computing, equipment networking, and multimedia control applications. Its active cooling design ensures stable performance across a wide operating temperature range.

Key Features

Processor Platform: Intel® Processor N-series, FCBGA1264 package
Memory: DDR4 SO-DIMM, up to 16GB, 3200 MHz
Storage:
- 1× SATA 3.0 (6Gb/s)
- 1× M.2 Key-B+M SSD slot
Expansion:
- 1× mPCIe (PCIe / USB 3.0 signal)
- 1× M.2 Key-B 3052 (USB 3.0 signal) for 4G/5G or wireless modules
Display Outputs: 1× VGA + 1× HD
Networking (Optional): 1× RJ45 LAN or 2× RJ45 LAN
USB Ports:
- Front: 4× USB-A 2.0
- Rear: 2× USB-A 3.0 + 2× USB-A 2.0 (optional)
Audio: Line-out + Mic-in (front and rear)
Buttons: Start / Restart button on the front panel
Reserved Interfaces: 2× COM ports and antenna hole
Cooling: Active cooling with 1× CPU fan
Power Input: DC 12V / 4A or higher
Chassis Size: 197 × 195 × 46 mm
Weight: 1.05 kg (net), 1.55 kg (with accessories)
Operating Environment: 0–60°C, 5–90% RH (non-condensing)

Typical Application Scenarios

Industrial Control & Automation: A compact controller for production lines, PLC integration, and industrial HMI/SCADA gateways.
Edge Computing & Data Collection: Ideal for on-site processing, data logging, and protocol conversion at the network edge.
Equipment Networking: Connects industrial devices and sensors to LAN, with optional dual-LAN for segmented networks.
Digital Signage & Multimedia Control: Drives displays through VGA/HDMI for kiosks, signage, and media playback systems.
Wireless / Cellular Expansion: Add Wi-Fi or 4G/5G modules via mPCIe or M.2 Key-B for remote connectivity.
