The 1264-10 is an ultra-compact, low-power industrial motherboard based on the Intel Processor N-series / Alder Lake-N platform. Designed for edge computing, industrial automation, embedded terminals, IoT gateways, and network communication applications, it combines efficient computing performance, dual 2.5GbE networking, DDR5 memory, and flexible expansion in a compact 110×100 mm motherboard form factor.
With 2×Intel I226V 2.5GbE LAN ports, DDR5 SO-DIMM memory support, M.2 storage, M.2 Key-E wireless expansion, PCI-E x6-IO expansion, DP/HD display output, COM, GPIO, and DC 12V~24V wide-voltage input, the 1264-10 is well suited for space-constrained industrial systems requiring stable operation, flexible I/O, and reliable high-speed connectivity.
Key Features
- Intel Processor N-series / Alder Lake-N platform for efficient low-power industrial and embedded computing
- Ultra-compact motherboard design with a 110×100 mm form factor for space-limited systems
- DDR5 SO-DIMM memory support, up to 16GB, 4800 MT/s for responsive embedded workloads
- Dual 2.5GbE RJ45 LAN ports powered by Intel I226V controllers for reliable high-speed networking
- M.2 Key-B+M 2280 storage supporting PCIe x1 and SATA 3.0 for flexible SSD deployment
- PCI-E x6-IO expansion interface with non-standard definition for customized industrial expansion
- M.2 Key-E 2230 CNVi slot for wireless connectivity options
- Dual display output: 1×DP and 1×HD, with optional custom eDP support
- Industrial onboard I/O: 2×F_USB 2.0, 1×J_COM, 1×J_GPIO, CPU_FAN, and reserved SFP_FAN
- IT8613E-LX I/O chip for GPIO, COM, and fan control functions
- Wide-voltage DC input: DC 12V~24V for industrial power environments
- Wide operating temperature: -20°C to 60°C for demanding embedded deployments
Application Scenarios
- Edge computing nodes
- Industrial automation systems
- Embedded terminal devices
- Network communication equipment
- IoT gateways
- Industrial control systems
- Compact network security devices
- Data acquisition terminals
- Smart equipment controllers
- Space-constrained embedded systems
Specifications
| Model | 1264-10 |
| Product Type | Industrial Embedded Motherboard |
| Processor Platform | Intel Processor N-series / Alder Lake-N |
| Socket | FCBGA1264 |
| Graphics | Intel UHD Graphics |
| Memory | DDR5 SO-DIMM, up to 16GB, 4800 MT/s |
| Storage | 1×M.2 Key-B+M 2280, PCIe x1 / SATA 3.0 |
| Network | 2×2.5GbE RJ45 |
| Network Controller | 2×Intel I226V |
| PCIe Expansion | 1×PCI-E x6-IO, non-standard definition |
| Wireless Expansion | 1×M.2 Key-E 2230 CNVi |
| Display | 1×DP, 1×HD, 1×eDP custom order |
| USB | 2×USB-A 3.2, 1×USB-A 2.0 |
| I/O Chip | IT8613E-LX for GPIO, COM, and fan control |
| Onboard I/O | 2×F_USB 2.0, 1×J_COM, 1×J_GPIO |
| Fan Header | 1×CPU_FAN, 1×SFP_FAN reserved |
| Power Input | 1×Jack DC 5.5/2.5 mm |
| Power Supply Mode | DC 12V~24V |
| Motherboard Size | 110×100 mm |
| Operating Temperature | -20°C to 60°C |
| Storage Temperature | -20°C to 70°C |
| Humidity | 5%~90% relative humidity, non-condensing |
Download
Note: Product appearance and specifications may vary slightly by production batch. For processor configuration, DDR5 memory compatibility, M.2 SSD support, PCI-E x6-IO expansion, wireless module support, eDP customization, GPIO/COM usage, or embedded system integration requirements, please contact us before ordering.
