The G31F-1264NP-6L is a high-performance embedded industrial computer designed for network applications and edge computing. Powered by an Intel Processor N-series, it integrates 6×2.5GbE RJ45 Ethernet ports, high-speed DDR5 memory, dual M.2 storage, SATA storage, mPCIe expansion, and a SIM card slot in a compact metal chassis. Equipped with an intelligent active cooling system, it helps ensure stable operation under sustained workloads, making it an ideal platform for users with demanding requirements for network throughput, data read/write performance, industrial IoT gateways, virtualized nodes, lightweight servers, and edge deployments.
Key Features
- Intel Processor N-series platform for efficient embedded network computing
- Active cooling design with 1×intelligent fan for stable operation under continuous workloads
- 6×RJ45 2.5GbE LAN ports powered by Intel I226V controllers
- DDR5 SO-DIMM memory support, up to 16GB, 4800 MT/s
- Dual M.2 storage: 2×M.2 Key-M 2280, PCIe x1
- Additional storage support: 1×SATA 3.0 6Gb/s
- mPCIe expansion slot with USB 2.0 signal for wireless or communication modules
- SIM card slot for cellular communication module applications
- Display output: 1×DP and 1×HD
- Industrial console interface: 1×RJ45 COM RS232
- USB connectivity: 4×USB-A 2.0
- Compact metal chassis: 178×126×56 mm for space-constrained deployments
- DC 12V power input, recommended 12V 4A or higher
Application Scenarios
- Network applications
- Firewall and software router systems
- Industrial IoT gateways
- Virtualized nodes
- Lightweight servers
- Embedded terminals
- Network security appliances
- Edge computing deployments
- High-throughput network transmission and data read/write applications
Specifications
| Model | G31F-1264NP-6L |
| Processor Platform | Intel® Processor N-series |
| Socket | FCBGA1264 |
| Memory | DDR5 SO-DIMM, up to 16GB, 4800 MT/s |
| Storage | 2×M.2 Key-M 2280 PCIe x1, 1×SATA 3.0 6Gb/s |
| Network | 6×RJ45 2.5GbE LAN |
| Network Controller | 6×Intel I226V |
| Expansion | 1×mPCIe with USB 2.0 signal |
| SIM | 1×SIM card slot |
| USB | 4×USB-A 2.0 |
| Display | 1×DP, 1×HD |
| Console | 1×RJ45 COM RS232 |
| Antenna Hole | 2×reserved |
| Cooling Method | Active cooling, 1×intelligent fan |
| Chassis Size | 178×126×56 mm |
| Weight | Equipment weight: 1.25 kg; package weight: 1.95 kg including accessories |
| Power Input | DC 12V 4A or higher |
| Operating Temperature | 0~50°C |
| Humidity | 5%~90% relative humidity, non-condensing |
Download
Note: Product appearance and specifications may vary slightly by production batch. Please refer to the actual product received or contact us before ordering if you need to confirm a specific configuration.
